RRC2054

Standard battery pack RRC2054 (4S1P)
with 15.00V / 3.20Ah / 48.00Wh

  • Worldwide approvals and certification of safety standards
  • No development costs, fast time-to-market
  • Smart batteries with numerous features according to the SMBus specification
  • Integrated LED State of Charge (SoC) indicator
  • State-of-the-art lithium-ion cells with the market’s highest energy density
  • High discharge performance
  • JEITA charging profile optimization
  • Numerous and redundant safety features, e.g.:
    • CUV (Cell Under Voltage): protection against deep discharge
    • COV (Cell Over Voltage): protection against over charge
    • OTC (Over Temperature in Charge): Protection against overheating while charging
    • OTD (Over Temperature in Discharge): Protection against overheating during discharging
  • Increased ESD protection up to 8kV
  • SHA-1 cryptosystem to prevent plagiarism

Are you looking for more information?

Product data sheet RRC2054

General
Delivery status (battery capacity)30%
Operating temperature0°C to 45°C (charge)
-20°C to 60°C (discharge)

Storage temperature

-20°C to 60°C max.
-20°C to 25°C recommended

Compliance information

CE / UL2054 / FCC / PSE / KC / Gost / EAC / CQC / RCM / IEC62133 / UN38.3 / ROHS / REACH / BIS

Electrical Parameters

Nominal voltage

15.00V

Nominal capacity

3.20Ah

Initial impedance

<270mΩ @ 1kHz at 20°C

Max. charge current

2.17A

Max. charge voltage

17.40V

Cont. discharge current

4.25A

Peak discharge current

10.00A

Life expectancy @25°C
1.60A Charge/1.60A Discharge

>300 cycles with min. 75% of initial capacity

Battery Dimensions

Length

85.10mm ±0.25

Width

77.40mm ±0.25

Thickness

22.40mm +0.60/-0.40

Weight

240g

Contacts

+, C, D, T, -

Safety Parameters PCM

Overcharge detection voltage / cell

4.42V

Overcharge release voltage / cell4.20V

Overdischarge detection voltage / cell

2.75V

Overdischarge release voltage / cell3.00V

Overcharge detection current

2.40A

Overdischarge detection current

4.35A


POWERPAQ RRC2054 is approved worldwide
